Camera
| Image Sensor | 6.23 mm (1/2.9 Type) CMOS |
| Lens | 4 mm F2.1 |
| Min. Illumination | 0 lux @ IR LED on |
| Day / Night | ICR (Auto) |
| WDR | Digital (Automatic Tone Control) |
| Electronic Shutter | Auto |
| 3D-DNR | Auto |
| Gain Control | Auto |
| IR LEDs | 30 |
| IR Distance | 20 m |
| Focus | Fixed |
Video
| Video Format | AHD |
| Max. Frame Rate | 30 fps @ 1920 x 1080 (NTSC) 25 fps @ 1920 x 1080 (PAL) |
| Synchronization | Internal |
| Max. Transmission Distance | 500m (75Ω-5C) |
| Interface | BNC |
General
| Power Source | DC12V |
| Max. Power Consumption | 4.2 W |
| Operating Temperature / Humidity | -10˚C ~ 55˚C / 0% ~ 80%RH |
| Standard Approvals | UL, FCC, CE, KC, VCCI, Police (China) |
| Color / Material | White / Diecasting |
| Ingress Protection | IP66 |
| Dimension (Ø x H) | 70.3 x 66.0 x 172.8 mm |
| Weight | 340 g |
