Camera
Image Sensor : 6.4 mm (1/2.8 Type) CMOS
Mount Type : CS mountable
Min. Illumination (Color) : 0.05 lux @ F1.2 (1/30 sec, 50 IRE)
Min. Illumination (B/W) : 0.005 lux @ F1.2 (1/30 sec, 50 IRE)
Day / Night : ICR (Auto / Day / Night / External / Schedule)
WDR : Digital (Automatic Tone Control)
Focus : ABF
Image Setting : Mirror, V-Flip, Pivot, BLC, HSBLC, ATC, Defog, Exposure control, Brightness, White balance, 2D+3D Noise reduction, Color saturation, Sharpness
Video / Audio
Video Compression : H.264 (High profile supported) / MJPEG
Resolution : 2048 x 1536 / 1920 x 1080 / 1280 x 1024 / 1280 x 720 / D1 (720 x 576) / CIF (352 x 240)
Max. Frame Rate : 30 fps @ 2048 x 1536
Multi-Streaming : 4
ROI (Region of Interest) : Smart codec (Up to 8)
Privacy Mask : Yes (Up to 4)
Motion Detection : Yes
Video Analytics : Intrusion, Crossing line, Object counting, Object removal, Object desertion
Streaming on Motion : Yes
Text Overlay : Yes
Audio Compression : G.711, G.726
Two-way Audio : Yes
Audio Detection : Yes
Event
Event Trigger : Motion/Tamper detection, Video analytics, Audio detection, Alarm input
Event Notification : Relay out, Email, FTP
Pre/Post Event Buffering : 5 / 5 seconds
Interface
Analog Video Out : No
Audio In / Out : 1 In / 1 Out
Alarm In / Out : 1 In / 1 Out
RS-485 : Yes
Storage : Micro SD (Up to 64 GB)
Network
Ethernet : RJ-45 10/100BASE-T
Security : Password protection, HTTPS (SSL, TLS), IP filtering, IEEE 802.1X
Open Protocol : ONVIF 2.2 Profile S, PSIA 1.1
Protocol (IPv4/6) : TCP, UDP, HTTP, HTTPS, RTP, RTSP, DHCP, ICMP, QoS, UPnP port forwarding
Protocol (IPv4) : FTP, SMTP, NTP, ARP, SNMPv1/v2c/v3, DDNS(LG)
Web Viewer : Microsoft Internet Explorer 8.0 ~ 11
Video Management Software : LG Ipsolute VMS Suite, Mobile App (iPhone, iPad, Android)
Max. Connections : Up to 20
General
Power Source : DC12V / PoE
Max. Power Consumption : 6.9 W
Max. Input Current : 590 mA (DC12V) / 150 mA (PoE)
Operating Temperature / Humidity : -10˚C ~ 55˚C / 0% ~ 80%RH
Standard Approvals : UL, FCC, CE, KC, Police (China)
Language : English, Korean, Chinese, Japanese, Portuguese
Color / Material : Black & White / Diecasting
Dimension (W x H x D) : 76.5 x 67.0 x 136.5 mm
Weight : 356 g
