Camera
Image Sensor : 6.08mm (1/3 Type) CMOS
Lens : 3mm F2.0
Resolution : Up to 1280 x 1024
Min. Illumination : Color : 0.7 Lux @ F2.0/ B/W : 0.7 Lux @ F2.0
Day / Night : Digital (Auto / Day / Night)
WDR : 80 dB
Image Enhancement : Backlight Compensation / 2D+3D-DNR / Exposure Control / Sens-up Control / AGC / White Balance / Privacy Masking / EIS / Sharpness / Digital Zoom
Video/Audio
Video Compression : H.264 (High Profile Supported) / MJPEG
Frame Rate : 30 fps @ 1280 x 1024, 30fps @ 720p(HD)
Multi-Streaming : Dynamic Profile (Up to 7)
ROI Streaming : Yes
Open Protocol : ONVIF 1.02, PSIA 1.1
Event
Motion Detection : Yes
Event Notification : Email, FTP
Pre/Post Event Buffering : 5 / 5 Seconds
Interface
Video In / Out : 1 RCA Out
SD Slot : Micro SD
Network
Ethernet : RJ-45 10/100 BASE-T
Security : Password Protection, HTTPS (SSL, TLS)
Protocol : IPv4/6 - TCP/IP, UDP, HTTP, HTTPS, RTP, RTSP, DHCP, ICMP, IPv4 - FTP, SMTP, NTP, ARP, SNMP v1/v2c/v3, DDNS (LG)
Web Viewer : Microsoft Internet Explorer 7.0 or above
Video Management Software : LG Ipsolute VMS, Mobile Application
Connections : Up to 10
General
Power Source : PoE / DC12V
Power Consumption : 5.9 W
Operating Temperature / Humidity : -10°C ~ 50°C / 0% ~ 80%RH
Standard Approvals : UL, FCC, CE, KCC, Gongan
Color / Material : White / Plastic
Ingress Protection : -
Dome Cover : Clear type
3-Axis : Yes
Dimension (Ø x H) mm : 140 x 110
Weight : 506 g
