Camera
Image Sensor | 6.49 mm (1/2.8 Type) CMOS |
Lens | x30, 4.3-129 mm, F1.6-F5.0 |
Min. Illumination | Color1.0 lux @ F1.6, sens-up off0.02 lux @ F1.6, sens-up x64B/W0.1 lux @ F1.6, sens-up off0.0008 lux @ F1.6, sens-up x64 |
Day / Night | ICR (Auto / Day / Night) |
WDR | 80 dB |
IR LEDs | - |
IR Distance | - |
Image Enhancement | Backlight compensation / 3D DNR / Exposure Control / Sens-up Control / AGC / White Balance / Privacy masking / EIS / Sharpness / Auto Digital Zoom / Defog |
PTZ
Optical Zoom | x30 |
Panning Range & Speed | 0˚~360˚, Max. 500˚/sec |
Tilting Range & Speed | 0˚~180˚, Max. 500˚/sec |
Auto Panning | 2-8 Points |
Preset/ID | 256 |
Group touring | Max. 10 Groups |
Pattern | 4ea |
Auto Tracking | - |
Video / Audio
Video Compression | H.264 (High profile supported) / MJPEG |
Resolution | 1920 x 1080 / 1280 x 720 / D1 (704 x 480) / CIF (352 x 240) |
Max. Frame Rate | 30 fps @ 1920 x 1080 |
Multi-Streaming | Yes (Up to 7) |
ROI (Region of Interest) | Crop (Up to 4) |
Video Analytics | Motion detection |
Text Overlay | Yes |
Audio Compression | G.711, G.726 |
Two-way Audio | Yes |
Event
Event Trigger | Video analytics, Alarm input |
Event Notification | Relay Out / Email / FTP / Go to Preset |
Pre/Post Event Buffering | 5 / 5 seconds |
Interface
Analog Video Out | 1 BNC Out |
Audio In / Out | 1 In / 1 Out |
Alarm In / Out | 4 In / 2 Out |
RS-485 | - |
SD Slot | SD (Up to 32 GB) |
Network
Ethernet | RJ-45 10/100BASE-T |
Security | Password protection, HTTPS (SSL, TLS), IP filtering, IEEE 802.1X |
Open Protocol | ONVIF 2.2 Profile S, PSIA 1.1 |
Protocol | IPv4/6 - TCP, UDP, HTTP, HTTPS, RTP, RTSP, DHCP, ICMP, QoS, UPnP port forwarding IPv4 - FTP, SMTP, NTP, ARP, SNMPv1/v2c/v3, DDNS(LG) |
Web Viewer | Microsoft Internet Explorer 7.0 ~ 9.0 (32bit) |
Video Management Software | LG Ipsolute VMS Suite, Mobile App (iPhone, iPad, Android) |
Connections | Up to 10 |
General
Power Source | AC24V / PoE+ |
Max. Power Consumption | 25 W (AC) |
Operating Temperature / Humidity | -20°C ~ 50°C / 0% ~ 80%RH |
Standard Approvals | UL, FCC, CE, KCC, Police (China) |
Color | White |
Ingress Protection | IK10 / IP66 |
Dimension (Ø x H) | Ø195 x 229 mm |
Weight | 3.3 kg |
