Video
Camera Input | 8 channels |
Video Compression | H.264 |
Max. Frame Rate | NTSC 120 fps @ 1920 x 1080 240 fps @ 1280 x 720 240 fps @ 960 x 480 PAL 120 fps @ 1920 x 1080 200 fps @ 1280 x 720 200 fps @ 960 x 576 |
Live View Layout | 1 / 4 / 9 / 1+5 / 1+7 / SEQ |
Recording Mode | Continuous, Manual, Motion detect |
Max .Playback Channel | Monitor: 8ch Web: 4ch |
Event Triggers | Motion detection |
Event Notification | Email, Buzzer |
Video/Audio
Storage Max. Internal HDDs | 1 x 3.5’’ SATA (Max. 6 TB) |
Ethernet | RJ-45 10/100BASE-T |
Video Out | 1 x HDMI, 1 x VGA |
Video Input | 8 x BNC |
Audio In / Out | 4 In / 1 Out (RCA) |
Control | 1 x RS485 |
USB | 2 x USB 2.0 |
General
Power Source | DC12V / 2.5A |
Operating Temperature / Humidity | 0˚C ~ 40˚C / 0% ~ 80%RH |
Language | English, Korean, Chinese, Japanese |
Dimensions | 300.0 x 208.7 x 48.4 mm |
Weight | 0.98 Kg (HDD not included) |
