Video
| Camera Input | 16 channels |
| Video Compression | H.264 |
| Max. Frame Rate | NTSC 240 fps @ 1920 x 1080 480 fps @ 1280 x 720 480 fps @ 960 x 480 PAL 240 fps @ 1920 x 1080 400 fps @ 1280 x 720 400 fps @ 960 x 576 |
| Live View Layout | 1 / 4 / 9 / 12 / 16 / 1+5 / 1+7 / 2+8 / 1+9 / 1+12 / 4+9 / 1+13 / SEQ |
| Recording Mode | Continuous, Manual, Motion detect |
| Max .Playback Channel | Monitor: 16ch Web: 4ch |
| Event Triggers | Motion detection |
| Event Notification | Email, Buzzer |
Interface
| Storage Max. Internal HDDs | 1 x 3.5’’ SATA (Max. 6 TB) |
| Ethernet | RJ-45 10/100BASE-T |
| Video Out | 1 x HDMI, 1 x VGA |
| Video Input | 16 x BNC |
| Audio In / Out | 4 In / 1 Out (RCA) |
| Control | 1 x RS485 |
| USB | 1 x USB 2.0, 1 x USB 3.0 |
General
| Power Source | DC12V / 2.5A |
| Operating Temperature / Humidity | 0˚C ~ 40˚C / 0% ~ 80%RH |
| Language | English, Korean, Chinese, Japanese |
| Dimensions | 300.0 x 208.7 x 48.4 mm |
| Weight | 1.04 Kg (HDD not included) |
