Video/Audio
Video Input | IP : 64CH/1080p |
---|---|
Video Output | 1 VGA / 2 HDMI |
Audio In / Out | 1 RCA / 1 RCA |
Alarm In / Out | 2 / 2 |
Interface
Protocol | ONVIF, RTSP |
---|---|
Recording Mode | Continuous, Alarm, Motion, Instant, Panic |
Playback | Local monitor : 16 x 1080p @ 30fps Client : 8 x 1080p @ 30fps |
RAID | 0/1/5/6/10 |
Viewer Software | CMS (NVR Station) / Web / iOS app / Android app |
Video Comp. | H.264 |
Audio Comp. | G.711a / G.711u / ADPCM / G.722 / G.722.1c / AAC-LC |
External HDD type | 16 x 3.5" HDD / Max. 64TB |
Network
Network | 3 x Gigabite network port, RJ45 interface |
---|
General
Serial Interface | 2 x RS485 |
---|---|
Power Source | AC Free 100~240V |
Dimension/Weight | 483 x 500 x 156mm, 20kg |
